Tricycle batteries - Liyue Lithium Battery Solutions

PRODUCT FEATURES

Build-in smart BMS, with battery voltage, current, temperature and health management
Support in series and parallel connection
Bluetooth phone APP for battery monitoring
High protection grade-IP65, easy to carry
Standard VRLA battery case, can replace VRLA battery directly

REQUEST A QUOTE

DOWNLOAD DATASHEET

Description

FAQs

Request A Quote

Description

This is a high-performance 12V lithium-ion battery with a capacity of 12.8V 100Ah. Utilizing lithium iron phosphate (LiFePO4) technology, this battery offers exceptional safety, stability, and long life, making it ideal for a variety of applications. Key features of this battery include:

High Energy Density: Compared to traditional lead-acid batteries, LiFePO4 batteries provide higher energy density, meaning they can store more energy in a smaller and lighter package.
Long Lifespan: Boasting an extremely high cycle life of over 5000 charge and discharge cycles, this battery significantly outlasts lead-acid batteries.
High Safety: LiFePO4 batteries are chemically stable, minimizing the risk of thermal runaway, explosions, or fires, ensuring higher safety.
Fast Charging and Discharging: Supports high current fast charging and discharging, reducing charging time and enhancing convenience.
Environmentally Friendly: Free of harmful heavy metals like lead and cadmium, these batteries meet environmental standards and are eco-friendly.
Wide Operating Temperature Range: Capable of operating efficiently in temperatures ranging from -20°C to 60°C, making it suitable for various harsh environments.

This 12V LiFePO4 lithium-ion battery is ideal for solar energy storage systems, RVs, power tools, electric boats, emergency power supplies, and many other applications, making it the best choice for a high-efficiency power solution.

12.8V100Ah lithium ion battery Data Sheet:

Model/Parameters	EV-GLP12100
Rated Voltage	12.8V
Rated Capacity (0.2C，@25℃)	100Ah
Rated Energy	1280Wh
Material	LiFePO4
Operating voltage range	10.0V~14.6V
Dimension	L330W172H215mm
Weight	11kg
Build in BMS
Over-charge protection	Cell>3.65V
Over-discharge protection	Cell<2.6V
Over-current protection Short circuit protection	Charging: >145A,delay 1.5s; Discharging: >310A, delay 400mS;Short circuit: >1500A
Cell balance	Pulse, 250mA, 3.55V
Over temperature protection	Charging: 65℃Discharging: 65℃
Case material	ABS
Environment
Humidity	5%~95% relative humidity
Charging temperature	0℃~40℃
Discharging temperature	-20℃~60℃
Storage temperature	0℃~40℃
Service Life
Cycle life	5000 times, @0.2C, 25℃, 80%DOD
Design life	>10 years

FAQs

What’s the difference of pouch cell, round type and prismatic one?

Cylindrical cell: The world's earliest cylindrical lithium battery is invented by Japan SONY company in 1992 18650 lithium battery, because the invention has a long history, so the market penetration rate is very high, now there is a very mature production technology can ensure mass production and reduce the price, but a single capacity is small, is not suitable for large-capacity lithium battery design.

Prismatic cell: The shell is designed with the same steel shell or aluminum shell as the cylindrical cell, which has the advantage of being easy to pack, which is a compromise in the current market, because the manufacturing difficulty is not high, and the degree of automation is higher than that of the pouch cell, and it is easy to produce on a large scale to reduce the cost of industrial manufacturing and is favored by the market.

Pouch cell: The shell is encapsulated by an aluminum-plastic composite film, which has the characteristics of flexible, flat and bag-like design. This is the safest and highest energy density lithium battery to date. Pouch cells can be molded into a variety of shapes, making them highly adaptable to irregular spaces and unconventional designs.

The internal electrochemical principles of these three battery routes are the same, and the material composition is basically the same, but the packaging form and shape characteristics of the batteries are different, and the appropriate battery cells need to be selected according to the products of the final application.

How safe are Lithium-Ion Batteries?

Our LiFePO4 batteries have passed mandatory safety tests and have excellent chemical and mechanical structures. Safety performance tests include external short circuit tests, free fall, mechanical shock, high temperature, extrusion, overcharge, etc. The batteries do not catch fire or explode, greatly reducing the possibility of any harm. It is also worth mentioning that they are non-toxic, non-polluting, do not contain rare earth metals, and are environmentally conscious.

What information do I need to provide you if I want to build a home photovoltaic system?

First of all, the whole system mainly has photovoltaic panels, inverters, batteries, controllers, combiner boxes, engineering installation, etc., the most important thing is that solar panels, inverters and batteries are the big head, solar panels recommend you to choose monocrystalline silicon solar panels, batteries recommend lithium-ion batteries, these technologies are more advanced but the price is not particularly high, is the best choice in the comprehensive, and then choose off-grid, grid-connected or hybrid power grid according to your needs, and then tell us what the load of your household appliances is. We will match the most cost-effective package according to your needs and recommend it to you, and accompany and guide the installation throughout the process.

What does the solar system package include?

All the major and solar-specific components are included in the package:

Solar panels
Solar inverter
Batteries and connection & communication wires (for off-grid, and hybrid system)
Solar panel mounting hardware (customized to your case)
DC combiner box (if inverter requires)
4m² DC cables and MC4 connectors to connect the solar array to the inverter
IP65 DC disconnect switch between the solar strings and the inverter
DC Breaker between the inverter and the battery
Solar installations tools

What services are included in the after-sales service?
