12V lithium-ion battery series
PRODUCT FEATURES
Description
This is a deep cycle LiFePO4 battery, designed to deliver high performance and reliability for various applications. Utilizing advanced lithium iron phosphate (LiFePO4) technology, this battery offers outstanding safety, longevity, and efficiency. Here are some key features:
- Deep Cycle Performance: Engineered for deep cycle applications, this battery is perfect for scenarios where long-duration, continuous power is required, such as in solar energy systems and off-grid applications.
- High Capacity: With a capacity of 200Ah, this battery provides substantial energy storage, making it ideal for high-demand applications and ensuring longer run times between charges.
- Exceptional Lifespan: Capable of over 5000 charge and discharge cycles, this LiFePO4 battery significantly outlasts traditional lead-acid batteries, offering greater long-term value.
- Enhanced Safety: LiFePO4 chemistry is known for its stable and safe performance, reducing the risk of thermal runaway, explosions, or fires, and ensuring reliable operation.
- Fast Charging Capability: Supports rapid charging, allowing for reduced downtime and increased efficiency in energy management.
- Environmentally Friendly: Contains no harmful heavy metals like lead or cadmium, making it a greener choice that meets environmental standards.
- Wide Temperature Range: Operates effectively in a broad temperature range from -20°C to 60°C, making it suitable for various environmental conditions and ensuring consistent performance.
- Light weight and Compact: Compared to traditional batteries, this LiFePO4 battery is lighter and more compact, which simplifies installation and integration into different systems.
This rechargeable Lithium ion battery is perfect for applications such as solar energy storage, RVs, marine use, electric vehicles, and emergency backup power systems. It offers a robust and efficient power solution for those seeking reliable and long-lasting energy storage.
Lithium ion battery Data Sheet:
| Model/Parameters | EV-GLP12200 |
| Rated Voltage | 12.8V |
| Rated Capacity (0.2C，@25℃) | 200Ah |
| Rated Energy | 2560Wh |
| Material | LiFePO4 |
| Operating voltage range | 10.0V~14.6V |
| Dimension | L380*W194*H250 |
| Weight | 21kg |
| Build in BMS | |
| Over-charge protection | Cell>3.65V |
| Over-discharge protection | Cell<2.6V |
| Over-current protection Short circuit protection | Charging: >145A,delay 1.5s; Discharging: >310A, delay 400mS;Short circuit: >1500A |
| Cell balance | Pulse, 250mA, 3.55V |
| Over temperature protection | Charging: 65℃Discharging: 65℃ |
| Case material | ABS |
| Environment | |
| Humidity | 5%~95% relative humidity |
| Charging temperature | 0℃~+40℃ |
| Discharging temperature | -20℃~+60℃ |
| Storage temperature | 0℃~+40℃ |
| Service Life | |
| Cycle life | 5000 times，@0.2C，25℃, 80%DOD |
| Design life | >10 years |
FAQs
Can I replace lead-acid batteries with lithium batteries? What do I need to know?
Using lithium battery to replace lead acid battery, you need to consider capacity, power, and size requirements, as well as making sure you have the right charger.
On average Lithium-Ion batteries weight 5 times less than standard lead acid battery. Using life is 3-4 times longer than lead-acid batteries, without losing effectiveness over time.
How safe are Lithium-Ion Batteries?
Our LiFePO4 batteries have passed mandatory safety tests and have excellent chemical and mechanical structures. Safety performance tests include external short circuit tests, free fall, mechanical shock, high temperature, extrusion, overcharge, etc. The batteries do not catch fire or explode, greatly reducing the possibility of any harm. It is also worth mentioning that they are non-toxic, non-polluting, do not contain rare earth metals, and are environmentally conscious.
When do I need charge battery?
We suggest 80%DOD when using battery. When the battery capacity is less than 20% of the rated capacity, please charge it. This will help extend the using life. Charge temperature at 0-45℃ is good for battery.
Do your batteries have a smart battery management system?
For a battery pack, smart BMS is necessary and we will equipped with it. It has function of Over-charge, over-discharge, over-current, short circuit, high/low temperature control, cell balancing, etc.
Can I use my OEM charger?
First, you cannot use a lead-acid battery charger to charge a lithium battery. This will directly damage the battery. Second, when choosing a lithium battery charger, you need to match the battery voltage and charging current.
What services are included in the after-sales service?
- One-year warranty for battery cells
- three-year warranty for power battery packs
- five-year warranty for energy storage battery packs
- We also provide humanized extended warranty services, and have professionals follow up the whole process.
